Description
- Size: 1.00" x 1.20" (Without included hardware)
- Weight: 0.14 oz (Without included hardware)
PDF Files
- Data Sheet (MC33926 H-Bridge)
- Overview
- Motor driver: MC33926
- Motor channels: 1
- Minimum operating voltage: 5 V (Operation from 5 - 8 V reduces maximum current output)
- Maximum operating voltage: 28 V (The device is protected for transients up to 40 V)
- Continuous output current per channel: 2.5 A (Can be improved by addition of heat sink or forced air flow)
- Peak output current per channel: 5 A
- Current sense: 0.525 V/A
- Maximum PWM frequency: 20 kHz (SLEW pin should be HIGH for frequencies above 10 kHz)
- Minimum logic voltage: 2.5 V (Input HIGH threshold can be as high as 2.0 V)
- Maximum logic voltage: 5.5 V
- Reverse voltage protection?: Y (On motor voltage only; logic voltage does not have reverse protection)
